Washer fasteners exhibit different densities, resulting in varying weights per unit volume. This diversity in weight directly impacts the overall weight of the washer. To assist users in determining the weight of specific washers, a weight chart is often employed as a useful resource. These charts typically feature a table with columns representing various parameters, such as diameter, length, and corresponding weight.
We will explore some of the different types of Washer Fastener Weight Chart In Kg, mm, pdf
Weight Chart of Washer Fastener in mm, l and kg mention in the table below.
APPROX. WEIGHT IN KGS FOR 100 NOS | |||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|
SIZE | PLAIN PUNCHED WASHER IS:2016 |
HEAVY WASHER IS:6610 |
MACHINED WASHER IS:2016 |
SQUARE TAPER WASHERS | SPRING WASHER FLAT SECTION IS:3063-72 | SPRING WASHER SQUARE SECTION IS:6735-72 DIN: 7980 |
Size (Inches) | PLAIN PUNCHED WASHER BS:3410 TABLE 7 |
SPRING WASHER FLAT SECTION BS:1802-1951 | SPRING WASHER SQUARE SECTION BS:1802-1951 | |||
MACHINED | HIGH STRENGTH FRICTION GRIP |
||||||||||||
FOR CHANNELS IS:5372-75 |
FOR I-BEAM IS:5374-75 |
TYPE-B (CHANNELS) IS: 6649-85 |
TYPE-C ( I-BEAMS ) IS: 6649-85 |
||||||||||
M-3 | 0.01 | 0.01 | |||||||||||
M-4 | 0.02 | 0.02 | |||||||||||
M-5 | 0.04 | 0.04 | 0.03 | 0.03 | |||||||||
M-6 | 0.11 | 0.11 | 0.08 | 0.04 | 1/4″ | 0.21 | |||||||
M-8 | 0.20 | 0.21 | 1.10 | 1.20 | 0.16 | 0.11 | 5/16″ | 0.35 | |||||
M-10 | 0.39 | 1.60 | 0.40 | 1.00 | 1.10 | 0.25 | 0.20 | 3/8″ | 0.48 | ||||
M-12 | 0.58 | 1.90 | 0.62 | 2.00 | 2.20 | 2.00 | 1.80 | 0.38 | 0.23 | 1/2″ | 1.07 | ||
M-14 | 0.82 | 0.60 | 0.38 | ||||||||||
M-16 | 1.06 | 2.90 | 1.13 | 3.40 | 3.75 | 9.00 | 8.50 | 0.89 | 0.59 | 5/8″ | 1.85 | ||
M-18 | 1.27 | 0.97 | 0.66 | ||||||||||
M-20 | 1.64 | 4.40 | 1.72 | 5.80 | 6.70 | 8.50 | 8.00 | 1.52 | 1.23 | 3/4″ | 2.91 | ||
M-22 | 1.75 | 7.50 | 7.00 | 1.65 | 1.36 | 7/8″ | 4.27 | ||||||
M-24 | 3.11 | 6.30 | 3.30 | 13.50 | 16.00 | 6.50 | 6.00 | 2.62 | 1.81 | 1″ | 6.13 | ||
M-27 | 3.94 | 8.00 | 4.23 | 12.50 | 15.00 | 12.00 | 11.50 | 2.87 | 2.06 | 1.1/8″ | 7.69 | ||
M-30 | 5.05 | 10.10 | 5.36 | 16.50 | 18.70 | 17.50 | 16.00 | 4.43 | 3.20 | 1.1/4″ | 9.90 | ||
M-33 | 7.10 | 12.00 | 7.54 | 21.00 | 23.50 | 23.00 | 22.50 | 6.30 | 3.50 | ||||
M-36 | 8.73 | 14.60 | 9.20 | 25.50 | 29.20 | 26.50 | 26.00 | 6.73 | 5.25 | 1.1/2″ | 17.24 | ||
M-39 | 12.60 | 16.70 | 13.30 | 28.30 | 34.50 | 7.17 | 5.61 | ||||||
M-42 | 17.50 | 20.10 | 18.30 | 11.10 | 8.00 | ||||||||
M-45 | 21.20 | 22.20 | 22.00 | 11.70 | 8.53 | ||||||||
M-48 | 28.40 | 26.00 | 29.40 | 12.30 | 9.00 | 2″ | 27.78 | ||||||
M-52 | 31.90 | 33.00 | 18.20 | ||||||||||
M-56 | 47.90 | 19.30 | |||||||||||
M-60 | 51.60 | 20.30 | |||||||||||
M-64 | 55.40 | 21.80 | |||||||||||
M-68 | 57.40 | ||||||||||||
M-72 | 63.40 | 24.00 |
